Industrial structures

REFINERY THAI OIL CLEAN FUEL PROJECT - SHIRACHA - THAILANDIA - 2019-2020

REFINERY THAI OIL CLEAN FUEL PROJECT - SHIRACHA - THAILANDIA - 2019-2020 - DCRPROGETTI

Detailed design, drawing and 3D Tekla modeling of two steel and reinforced concrete structure with relevant pile foundations to support 4 vertical vessels 1000 tons each and 4 reactors 3000 tons each in operating condition. Steel structure and pipe rack modularized with analisys in different phases of construction, sea transportation, load out, lifting, and in-service condition.

CUSTOMER: SAIPEM SPA

ON GOING ACTIVITIES

MEXICO ORF DE-BOTTLENECK PROJECT - 2019

MEXICO ORF DE-BOTTLENECK PROJECT - 2019 - DCRPROGETTI

The activity concerns the construction, in a very short time, of an Oil Export Pump Station in order to increase the production of the new Oil & Gas Treatment Plant, not yet in operation, as part of the ORF DE-BOTTLENECK PROJECT Project, on behalf of ENI MEXICO and for the Mexican National Company PEMEX.

CUSTOMER: ENIPROGETTI SPA

UTE PORTO DE SERGIPE - I - Combined Cycle Power Plant - Brasile, 2017-18

UTE PORTO DE SERGIPE - I - Combined Cycle Power Plant -  Brasile, 2017-18 - DCRPROGETTI

Detailed design of 6 module structures for a total of 15 prefabricated steel modules, for the construction of a new Combined Cycle Power Plant & H.V. System located in Porto De Sergipe in Brazil.

The construction field of the modules, located in China, the subsequent maritime and land transportation and the installation/assembly in site required the design of the structures in all the moving phases.

In addition, the  reinforced concrete sumps and bases of the transformers were also designed, including the prefabricated fire walls.

CUSTOMER: RINA SPA

PETRONAS RAPID PROJECT - PKG 7 – EPCC OF THE FLEXI HDPE - MALAYSIA - 2016-2018

PETRONAS RAPID PROJECT - PKG 7 – EPCC OF THE FLEXI HDPE - MALAYSIA - 2016-2018 - DCRPROGETTI

Structural detailed design of pipe rack, structure and shelter entirely in reinforced concrete or steel or with the lower part in reinforced concrete and the upper part in steel, including pile foundations. Because the plant is located in a earthquake high risk zone, a modal analisys has been carried out with eurocodice.

CUSTOMER: GICOTECNICA SRL - TECNIMONT SPA

Khurais Facilities Expansion & Satellite GOSP (ARAMCO) SAUDI ARABIA - 2014-2018

Khurais Facilities Expansion & Satellite GOSP (ARAMCO) SAUDI ARABIA - 2014-2018 - DCRPROGETTI

Extension of the ARAMCO OIL & GAS Plant in Khurais - Saudi Arabia, already designed by our company between 2006 and 2008.

The intervention concerns the construction of new areas and the revamping of existing ones with the detailed design of steel structures with the relavant foundations and foundations of gas turbines.

CUSTOMER: SAIPEM SPA

EPC13 UTILITY PACKAGE - JAZAN REFINERY PROJECT (ARAMCO) SAUDI ARABIA - 2013-2016

EPC13 UTILITY PACKAGE - JAZAN REFINERY PROJECT (ARAMCO) SAUDI ARABIA - 2013-2016 - DCRPROGETTI

Detailed design of steel structures, pipe racks and shelter with relevant foundations.

Main Pipe Rack, some secondary pipe racks, Lagoon Shelter, Air Compressor Shelter and other shelter with various dimensions.

The site is in high seismic category with a design earthquake spectral response acceleration parameter equal to SDS = 0.421 as per ASCE/SEI 7-05.

CUSTOMER: HITACHI/GICOTECNICA SRL

BOCAMINA II - New Coal Power Plant FGD Gypsum silo - CHILE - 2008-2009

BOCAMINA II - New Coal Power Plant FGD Gypsum silo - CHILE - 2008-2009 - DCRPROGETTI

Detailed structural design of two reinforced concrete silos for the storage of gypsum obtained as a by-product from a desulphurisation system of a New Coal Power Plant.

 The site is classified by the Chilean Code as high seismic and tsunami risk with a maximum ground acceleration (PGA) equal to 0.4g for a earthquake with 50 years probability of exceedance.

The structure did not report any damage during the earthquake of February 2010 with an epicenter at 10 km and a magnitude equal to 8.8.

CUSTOMER: MAIRE TECNIMONT SPA









.

Khurais Facilities & Satellite GOSP (ARAMCO) SAUDI ARABIA - 2006 - 2008

Khurais Facilities & Satellite GOSP (ARAMCO) SAUDI ARABIA - 2006 - 2008 - DCRPROGETTI

Detailed Design of steel structures with relevat foundations.

CUSTOMER: POLARIS/SAIPEM SPA

Khursaniyah Facilities & Satellite GOSP (ARAMCO) SAUDI ARABIA - 2005 -2008

Khursaniyah Facilities & Satellite GOSP (ARAMCO) SAUDI ARABIA - 2005 -2008 - DCRPROGETTI

Detailed design of steel and reinforced concrete pipe racks, steel structures with relevant foundations and foundations of turbine, horizontal and vertical vessels, pumps and tanks.

CUSTOMER: SNAMPROGETTI SPA
